S-22 Multi-Core Fiber Fusion Splicer

The 1st Independent Research & Development Fully Automatic Multi-core Fiber Fusion Splicer

Different types of fibers can be spliced
Real-time ARC calibration, ARC position adjustable
Fiber profile/end view dual mode aligning technology
Suitable for 125~250μm multi-core fiber fusion splicing
Support software upgrade, fusion records/images export
Precision integrated propulsion and new focusing design
Support wind-proof cover open and close to work automatically
With battery inside, could be used for outdoor projects
Dual fiber end imaging patent, direct fiber end face view, more accurate alignment

Fully Automatic Multi-core Fiber Fusion Splicer

36CM x 27CM x 19CM

149MM x 120MM x 127MM

Applicable Fiber	Telecommunication Fibers: SM/MM/DS/NZDS/EDF
Applicable Fiber	Multi-core Fiber: 2, 4, 6, 7, 8 Cores Fiber
Cladding Diameter	125~250µm
Coating Diameter	250~900µm
Cleaved Length	9~15mm (standard)
Alignment Method View	PAS and fiber end-face direct view available
Typical Splicing Loss	SMF:0.03dB; 4-core fiber: 0.05dB (each channel); 7-core fiber: 0.15dB (each channel)
Typical Splicing Time	Single core fiber<20 seconds; Multi-core fiber<2 minutes
Operation Mode	Manual/Auto
Heating Mode	Manual/Auto
Typical Heating Time	Typical 30s, support user-defined setting
Splicing Program	40 modes
Battery Capacity	Detachable 6800mAh Li-battery
Electrode Life	>2000 times, easy to replace the electrodes
Data Storage	10000 groups fusion records, 100 groups images
Viewing Display	5”HD color LCD Monitor
Terminal	USB 2.0 port, for software upgrading, records exporting, RS232 port, output signal customizable
Dimension/Weight	330mm(L)x205mm(W)x172mm(H)/6.4kg
Operating/ Storage Condition	Altitude: 0~5000m; Humidity: 0~95%; Temperature: -10°C~+50°C; Max wind: 15m/s
Power Supply	Adaptor, input: AC100~240V(50/60Hz), output: DC11~13.5V, 5A
